TQ412 111-412-000-013 A1-B1-E010-F0-G000-H10 Proximity Transducer
Description
| Manufacture | Others |
| Model | TQ412 |
| Ordering information | 111-412-000-013 A1-B1-E010-F0-G000-H10 |
| Catalog | Probes & Sensors |
| Description | TQ412 111-412-000-013 A1-B1-E010-F0-G000-H10 Proximity Transducer |
| Origin | United States (US) |
| HS Code | 85389091 |
| Dimension | 16cm*16cm*12cm |
| Weight | 0.8kg |
Details
The TQ412 111-412-000-013 is a rugged proximity sensor designed for industrial applications requiring accurate non-contact object detection.
Key Features
Reverse mounting configuration: Ideal for space-constrained environments.
Integral coaxial cable: Simplifies installation and reduces connection points.
Ex iA explosion-proof: Suitable for use in hazardous environments.
Flexible cable options: Accommodates a variety of installation requirements.
Technical Specifications
Measuring principle: Eddy current
Maximum sensing distance: 9.8 mm (0.39 in)
Output signal: Analog voltage
Operating temperature range: -40 °C to +125 °C (-40 °F to +257 °F)
