| Manufacture |
Schneider |
| Model |
AS-BDAP-253 |
| Ordering information |
AS-BDAP-253 |
| Catalog |
Modicon |
| Description |
Schneider AS-BDAP-253 Modicon Input Module |
| Origin |
Franch(FR) |
| HS Code |
3595861133822 |
| Dimension |
5cm*16.5cm*22cm |
| Weight |
0.5kg |
| Manufacturer |
Schneider Electric |
| Series |
Compact 984 |
| Part Number |
AS-BDAP-253 |
| Module Type |
Mixed discrete input/output module |
| Weight |
0.52 lbs (0.24 kg) |
| Internal power |
<15 mA at 5 VDC |
| External power |
110 VDC ±40%, 70 mA at 24 VDC |
| Voltage range |
24 VDC to 154 VDC, 66 VDC to 154 VDC |
| Input type |
8 digital inputs |
| Output type |
4 relay-based outputs |
| Input thresholds |
ON: +55 VDC to +170 VDC, OFF: -2 VDC to +10 VDC |
| Relay isolation |
Outputs isolated per group |
| Current draw |
2.2 mA at 110 VDC (ON), 5 mA (wetting) |
| Timing response |
Input: 10 ms, Output: 6 ms |
| Groups |
1 input group, 4 output groups |
| Points per group |
8 input points, 1 output point |
| Slot requirement |
Occupies 1 slot |
