• CPUM/IOCN rack controller and communications interface card pair with support for Modbus RTU/TCP or PROFINET, and a front-panel display
• “One-Shot” configuration management of protection cards (MPC4 and AMC8) in a VM600 rack using an Ethernet or RS-232 serial connection to a computer running the MPSx software
• Front-panel display for visualisation of monitored outputs and alarm limits from protection cards
• Common alarm reset (AR) for protection cards and MPS rack (CPUM) security
• system event and measurement event logs available via the MPSx software

rack controller and communications interface card.

The CPUM and IOCN modular CPU card and input/output card is a rack controller and communications interface card pair that acts as a system controller and data communications gateway for a rack-based machinery protection system (MPS) and/or condition monitoring system (CMS).

Note: Different versions of CPUx/IOCx rack controller and communications interface card pair are available, as follows:

• The CPUM/IOCN is the original version with a front-panel display and support for Modbus RTU/TCP or PROFINET (PNR 200-595-VVV-VVV).
• The CPUR/IOCR is a version with rack controller redundancy and support for Modbus RTU/TCP (PNR 600-007-VVV-VVV).
• The CPUR2/IOCR2 is a version with mathematical processing of fieldbus data and support for Modbus TCP and PROFIBUS DP (PNR 600-026-000-VVV).

Features

• CPUM/IOCN rack controller and communications interface card pair with support for Modbus RTU/TCP or PROFINET, and a front-panel display
• “One-Shot” configuration management of protection cards (MPC4 and AMC8) in a rack using an Ethernet or RS-232 serial connection to a computer running the MPSx software
• Front-panel display for visualisation of monitored outputs and alarm limits from protection cards
• Common alarm reset (AR) for protection cards and MPS rack (CPUM) security
• system event and measurement event logs available via the MPSx software
•
