GE IS230PCAAH1B Core Analog I/O Module
Description
| Manufacture | GE |
| Model | IS230PCAAH1B |
| Ordering information | IS230PCAAH1B |
| Catalog | Mark VI |
| Description | GE IS230PCAAH1B Core Analog I/O Module |
| Origin | United States (US) |
| HS Code | 85389091 |
| Dimension | 16cm*16cm*12cm |
| Weight | 0.8kg |
Details
IS230PCAAH1B Core Analog I/O Module Description
The IS230PCAAH1B is a Core Analog I/O Module designed and manufactured by General Electric (GE), as part of the Mark VIe Series, which is used in distributed control systems (DCS).
This module plays a crucial role in providing a significant portion of the analog signal I/O needed to operate complex systems such as gas turbines.
The Core Analog (PCAA) module works in conjunction with the related Core Analog Terminal (TCAS and TCAT) boards, delivering a wide range of analog signals that are essential for the control and monitoring of industrial processes.
The PCAA module supports various types of input and output signals, including thermocouple inputs, 4-20 mA current loops, seismic inputs, linear variable differential transformer (LVDT) excitation and inputs, pulse rate signals, and servo coil outputs.
These capabilities make the PCAA module versatile, capable of interfacing with a wide array of sensors and actuators used in turbine and other industrial systems.
The IS230PCAAH1B module is designed to be compatible with simplex, dual, and TMR (Triple Modular Redundant) systems, offering flexibility in both single and redundant configurations.
It can operate in systems that require high reliability, such as those found in power plants and critical industrial applications. A single TCAT terminal board connects to one, two, or three PCAA modules, enabling the distribution of signal inputs.
This architecture allows for scalable and flexible system configurations to meet varying operational needs.
In addition to the terminals on the PCAA and TCAT modules, the JGPA board, located nearby, provides additional connections.
This includes shield ground and 24 V field power connectors, further enhancing the system’s grounding and power distribution capabilities. These features ensure reliable operation in electrically noisy environments, typical of industrial settings.
In summary, the IS230PCAAH1B Core Analog I/O Module is an integral component of the GE Mark VIe Series, providing essential analog I/O functionality for controlling and monitoring complex industrial systems like gas turbines.
It offers flexibility, reliability, and scalability, making it suitable for a wide range of applications requiring precise analog signal processing.
