GE IS200TREGH1BDB Trip Emergency Termination Board
Description
| Manufacture | GE |
| Model | IS200TREGH1B |
| Ordering information | IS200TREGH1BDB |
| Catalog | Mark VI |
| Description | GE IS200TREGH1BDB Trip Emergency Termination Board |
| Origin | United States (US) |
| HS Code | 85389091 |
| Dimension | 16cm*16cm*12cm |
| Weight | 0.8kg |
Details
GE IS200TREGH1B as a trip emergency terminal board. Manufactured for the Mark VI series.
Used to monitor switch status, sensor signals, alarm signals, etc. during the production process to achieve real-time monitoring and control of the production process.
Mark VI is the latest series in GE's Mark series. These series are designed for the operation and automation of steam and gas turbines.
The components on this device are a series of square transformers. These transformers are covered in clear plastic and silver wire. These cover functional information about the component, such as part number and voltage.
There are twelve of these transformers on the IS12TREGH200B, six transformers per vertical line. Two large black terminal blocks take up space on the left edge of the IS200TREGH1B.
The terminal block contains a total of forty-eight terminals made of silver metal. The terminals are divided equally between the two terminal blocks, with twenty-four assigned to each terminal block.
The IS200TREGH1B contains a number of components called metal oxide varistors, or MOVs. These MOVs are round and solid red. They are placed on the edge of the IS200TREGH1B. Three white jumper ports have been placed on the top edge of the IS200TREGH1B.
The connector on the left has three ports and is labeled JH1. The middle connector contains twelve ports identified as J2, and the last connector on the right has two ports identified as J1.
