ABB DSDO 115A 3BSE018298R1 Digital Output Board
Description
| Manufacture | ABB |
| Model | DSDO 115A |
| Ordering information | 3BSE018298R1 |
| Catalog | Advant OCS |
| Description | DSDO 115A Digital Output Board 32 Channe |
| Origin | Sweden (SE) |
| HS Code | 85389091 |
| Dimension | 16cm*16cm*12cm |
| Weight | 0.8kg |
Details
S100 I/O is the group of input and output boards located in the I/O subrack. The I/O subrack
communicates with the controller subrack using Bus Extension to S100 I/O. Single and redundant Bus Extension to S100 I/O are available. Redundant S100 I/O Bus Extension requires redundant processor module. Electrical and optical bus extensions are provided. See the outline presentation of the bus extension in Section 1.7.7, Communication or to the separate documentation mentioned.
Information in this section is divided according to the different categories of boards and subdivided into Regarding connection units and internal cables used in the hazardous and HART applications you are referred to the separate documentation.
Analog outputs are available for standard voltage and current signals. • There are both isolated and non-isolated outputs. • Optional redundancy is featured, where one type of board can be duplicated to achieve increased availability. • A board is offered which combines analog inputs and analog outputs (loop dedicated I/O). • An output is read out each time new values are entered into the data base. • Optional software limitations can be selected.
